Omega Products DV50 Hydraulic Expansion Chuck - HC20s (Fig.2) 25,000RPM G2.5
OM32164
Availability: Next Day delivery subject to availability
These chucks are built according to the DIN69871 standard, ensuring compatibility with a wide range of machining centres and tool holders. With a maximum operating speed of 25,000 RPM, they can handle demanding machining operations with ease. The hydraulic expansion mechanism of these chucks allows for quick and precise clamping of cutting tools. By utilizing hydraulic pressure, the chuck expands evenly to securely grip the tool, providing excellent stability and vibration damping during machining. This feature contributes to improved surface finish, dimensional accuracy, and extended tool life.
Taper | DV50 |
Collet Size (d) | 20 |
Nose Diameter (D1) | 50 |
Gauge Length (L) | 64.5 |
Thread (M) | M16 |
L1 | 42 |
Fig. | Fig.2 |
Form | AD/B + Cool |
Balance | G2.5@25000RPM |
These chucks are built according to the DIN69871 standard, ensuring compatibility with a wide range of machining centres and tool holders. With a maximum operating speed of 25,000 RPM, they can handle demanding machining operations with ease. The hydraulic expansion mechanism of these chucks allows for quick and precise clamping of cutting tools. By utilizing hydraulic pressure, the chuck expands evenly to securely grip the tool, providing excellent stability and vibration damping during machining. This feature contributes to improved surface finish, dimensional accuracy, and extended tool life.
Taper | DV50 |
Collet Size (d) | 20 |
Nose Diameter (D1) | 50 |
Gauge Length (L) | 64.5 |
Thread (M) | M16 |
L1 | 42 |
Fig. | Fig.2 |
Form | AD/B + Cool |
Balance | G2.5@25000RPM |
